For detailed drawing please click on the PDF file available for each individual unit below.
Code | Dimensions mm (length x depth x height) | Drawing |
---|---|---|
09-6-1650-DB-L | 1650 x 600 x 900 | 09-6-1650L-DB-F.dwg 09-6-1650L-DB-P.dwg 09-6-1650L.pdf |
09-6-1650-DB-R | 1650 x 600 x 900 | 09-6-1650R-DB-F.dwg 09-6-1650R-DB-P.dwg 09-6-1650R.pdf |
09-6-1800-DB-L | 1800 x 600 x 900 | 09-6-1800L.DWG 09-6-1800L.PDF |
09-6-1800-DB-R | 1800 x 600 x 900 | 09-6-1800R.DWG 09-6-1800R.PDF |
09-7-1650-DB-L | 1650 x 700 x 900 | 09-7-1650L-DB-F.dwg 09-7-1650L-DB-P.dwg 09-7-1650L.pdf |
09-7-1650-DB-R | 1650 x 700 x 900 | 09-7-1650R-DB-F.dwg 09-7-1650R-DB-P.dwg 09-7-1650R.pdf |
09-7-1800-DB-L | 1800 x 700 x 900 | 09-7-1800L.DWG 09-7-1800L.PDF |
09-7-1800-DB-R | 1800 x 700 x 900 | 09-7-1800R.DWG 09-7-1800R.PDF |
